DOT-Compliant Coil Protectors: USA-Made to Meet FMCSA Standards

When your cargo is on the line along with your compliance record, you need coil protectors you can count on from a manufacturer you can trust.

Dogtooth Products coil protectors: DOT-compliant, precision injection molded, entirely made in the U.S.A.

DOT Steel Coil Securement Regulations – 49 CFR 393.120, 49 CFR 393.104, and 49 CFR 393.106

Keep Your Coil Shipping Operation Within Compliance

When transporting steel coils in an eye-cross configuration, federal guidelines require multiple chain tie-downs, proper tensioning, and edge protection to prevent abrasion and shifting. Our coil protectors are designed to safeguard chains at critical contact points, reduce wear, and support compliant securement systems for coils over 10,000 lbs. From diagonal eye-cross chains to transverse top restraints, our products provide durable protection you can rely on while staying within regulation.

DOT-compliant coil protectors are a critical part of meeting federal regulations regarding the transporting steel or aluminum coils on flatbed trailers. More than that, proper coil protectors go further than protecting your load, likewise protecting your trucks, trailers, and related equipment. They also protect your business from costly violations and potentially creating unsafe conditions out on the road.

At Dogtooth Products, we manufacture plastic coil protectors specifically designed to help flatbed carriers stay safe and compliant, shipment after shipment.

Why FMCSA Compliance Matters

The Federal Motor Carrier Safety Administration (FMCSA) enforces strict cargo securement regulations under 49 CFR Part 393, Subpart I, specifically 49 CFR § 393.120, which governs the securement of metal coils. These rules apply to any metal coil shipment weighing 5,000 pounds (2,268 kg) or more, and they carry real consequences for non-compliance: roadside violations, out-of-service orders, fines, and increased CSA scores that can affect your operating authority.

Similarly, 49 CFR § 393.104 lays out standards for cargo securement devices and systems, while 49 CFR § 393.106 lays out general requirements for securing cargo loads.

These FMCSA rules exist because improperly secured loads are a leading cause of commercial vehicle accidents. When coils shift, tip, or roll off a flatbed, the results can be catastrophic for the driver, other motorists, and the cargo itself.

DOT / FMCSA Requirements for Steel and Aluminum Coil Transport

Tiedowns must be arranged to prevent the coil from tipping or shifting in the forward, rearward, and lateral directions
Coils transported with the eye crosswise or lengthwise must use a means (such as timbers, chocks, wedges, or a cradle) to prevent rolling, and that means must support the coil off the deck
Tiedowns must be positioned as close as practicable to the eye of the coil and arranged to prevent them from slipping or becoming unintentionally unfastened during transit
Edge protection is mandatory at any contact point where a tiedown runs over a sharp or abrasive surface that could damage or weaken the chain or strap

Dogtooth Coil Protectors

Dogtooth Products’ plastic coil protectors are engineered to satisfy the edge protection requirements of 49 CFR § 393.120, serving as the protective barrier between your chains and the edges of your steel or aluminum coils.

Protect tiedown integrity by cushioning the chain contact point, distributing load tension and preventing the cutting or fraying that sharp coil edges cause over time.
Work across all coil orientations whether loaded eye-to-the-sky or eye-to-the-side. Dogtooth protectors are designed to work seamlessly with your securement configuration.
Built-in handles for fast, reliable placement, featuring two integrated handles that make installation quick and precise, reducing setup time and helping ensure the protector is properly positioned every time.
Durable, reusable construction built from heavy-duty plastic to withstand repeated use across multiple shipments without cracking or deforming — keeping them inspection-ready and compliant haul after haul.

Applicable for steel and aluminum coil transport, from raw steel used in fabrication to aluminum coils headed to manufacturing facilities. Dogtooth protectors perform reliably across the coil types flatbed carriers haul most.

American-Made Protection You Can Count On

Dogtooth Products is a Veteran-Owned American manufacturer with decades of combined experience working with industrial-grade plastic. Every coil protector we produce is made in the USA by a team that understands the demands of the flatbed trucking industry. We don’t outsource our manufacturing or cut corners on materials. Because when your equipment is rolling down the highway at highway speed with tens of thousands of pounds on the trailer, there’s no room for inferior products.
